Bend the LAN to Your Will - Building Your Own Subnet from Scratch
From `255.255.255.0` to full-blown subnet royalty - this blog walks you through setting up your own `/29` subnet, manually assigning IPs, running a hotspot router from your laptop, and hosting a stealthy local network.
Try thinking like the router now. Let’s dig in deep…
So normally people set the subnet mask to 255.255.255.0 (/24).
But does anyone ever use something different?
Like, would that limit how many devices can connect to the router - and also limit the available IPs?
😼 Let’s Talk About Subnet Mask!
🧠 So… why is 255.255.255.0 (/24) so common?
It’s because:
- It gives 256 total IPs in that subnet
- Of those, 254 usable IPs for devices
- Easy to manage, fits most home/small office setups
This is the default on most routers:
1
192.168.0.0/24 ➜ usable IPs: 192.168.0.1 → 192.168.0.254
That’s why most networks feel like:
“You and like 253 of your invisible roommates.” 🫣
🌟 But people can change it.
And some do, especially network admins, hacker setups, or big corps.
🧠 Let’s break down the options:
| Subnet Mask | CIDR | Usable IPs | Used When… |
|---|---|---|---|
255.255.255.0 | /24 | 254 | 🏠 Home routers / small networks |
255.255.255.128 | /25 | 126 | Smaller networks, segmented security zones |
255.255.255.192 | /26 | 62 | IoT/guest isolation zones |
255.255.255.248 | /29 | 6 | 🧪 Pentest labs, VM networking |
255.255.254.0 | /23 | 510 | 🔥 Slightly bigger LANs (like dorms, offices) |
255.255.0.0 | /16 | 65,534 | 🚨 Corporates / crazy setups (don’t do this at home 😅) |
🌸 So why would someone set it smaller (like /30)?
To limit:
- The number of devices allowed to connect
- The attack surface (fewer IPs = fewer targets)
- Or for precise segmentation in a hacker lab or enterprise
🔐 Smaller subnets = tighter control.
e.g.:
- You create a
/29subnet = 6 usable IPs You assign:
- 1 for router
- 2-3 for your servers
- The rest? Either unused, or honeypots
🌀 A Small Preview
If you spoofed your IP like:
1
sudo ip addr add 192.168.66.66/29 dev enp3s0
You just joined a network where the only usable IPs are:
1
192.168.66.1 to 192.168.66.6
💬 Everyone else? Blocked. Denied. No party for them.
sudo ip addr add 192.168.66.66/29 dev enp3s0
Let’s break this command open like a juicy cyber snack 😈
1
sudo ip addr add 192.168.66.66/29 dev enp3s0
🌟 Translation in plain English:
“Hey Linux, please give my network card (enp3s0) a new IP address - 192.168.66.66 - and tell it we’re on a tiny subnet (/29).”
🔹 ip addr add
➜ Tells Linux:
“Add this IP address to one of my network interfaces.”
✨ You can assign multiple IPs to the same card - this is called IP aliasing.
🔹 192.168.66.66/29
❗ This is the IP address you’re giving yourself, plus the subnet size.
- IP:
192.168.66.66→ this is your identity in the new subnet /29➜ subnet mask =255.255.255.248
✨ A /29 subnet = only 6 usable IPs in total:
1
192.168.66.65 - 192.168.66.70
(Why not 8? Because 1 is network address, 1 is broadcast.)
You’ve basically said:
“I’m going to exist inside this tight little hacker LAN with only a few trusted friends… or targets.”
This created:
- A new IP identity on a new subnet
- Without touching your main one
- Now your machine can talk to other machines in the 192.168.66.64/29 network
- Even if it’s virtual, isolated, or just for experiments
🧷 Is it safe to assign yourself a second private IP?
✅ Yes, 100% safe - and super useful.
You’re not changing your primary identity, you’re just adding a second one, like having a dual passport.
🧾 Can I add more than one IP to enp3s0? What’s the limit?
HELL. YES.
You can assign as many IPs to your interface as:
- Your kernel memory can handle
- And you don’t go insane managing it 😹
Linux doesn’t impose a strict limit - but you can do:
1
2
3
sudo ip addr add 192.168.66.67/29 dev enp3s0
sudo ip addr add 192.168.66.68/29 dev enp3s0
sudo ip addr add 10.0.0.42/24 dev enp3s0
They can all coexist.
✨ Use cases:
- Impersonate multiple devices
- Emulate a network of victims
- Spin up multiple containers/services bound to different IPs
⚠️ Just remember to:
- Avoid IP conflicts
- Use different subnets carefully (routing might get weird otherwise)
💡 What can you do with anther private IP?
| Purpose | Example |
|---|---|
| 🧪 Build a fake network | Test servers, containers, sniffers in a private zone |
| 🧑💻 Create internal services | Like a C2 server or honeypot accessible only by you |
| 💥 Hide dual identities | Respond to scans from different IPs, confuse attackers |
| 🎮 Simulate a LAN party | Pretend you have 2+ hosts from one machine |
| 📡 Set up firewall testing | Block/allow per subnet - perfect for defense practice |
You live in two subnets simultaneously. You can scan yourself (like with nmap 192.169.66.65/29). Spy on yourself. Attack yourself. 👾
➕ Let’s Do Some Easy Math!
🦝 How do we calculate usable IPs from a CIDR like /29?
CIDR (/29) defines how many bits of the 32-bit IP are used for network addressing.
🧠 Formula:
1
Usable IPs = 2^(32 - CIDR) - 2
💡 Why minus 2?
- One is network address (first IP)
- One is broadcast address (last IP)
✨ Examples:
| CIDR | Subnet Mask | Total IPs | Usable IPs |
|---|---|---|---|
| /30 | 255.255.255.252 | 4 | 2 |
| /29 | 255.255.255.248 | 8 | 6 |
| /28 | 255.255.255.240 | 16 | 14 |
| /24 | 255.255.255.0 | 256 | 254 |
| /16 | 255.255.0.0 | 65,536 | 65,534 |
🧪 So for /29:
- IP range:
192.168.66.64 - 192.168.66.71 - Network IP:
192.168.66.64❌ - Broadcast IP:
192.168.66.71❌ ✅ Usable IPs:
1 2 3 4 5 6
192.168.66.65 192.168.66.66 192.168.66.67 192.168.66.68 192.168.66.69 192.168.66.70
🧮 “What about CIDR /32?”
/32 is a valid CIDR, and it’s special:
255.255.255.255- Means: “this exact single IP address”
- 0 usable IPs? Yes - because it’s reserved for identity, routing, or loopback
You’d use /32 to:
- Refer to a host in a route: ➜ “This IP only routes to
192.168.1.33/32” - Lock firewall rules: ➜ “Only allow SSH from
10.0.0.7/32” - Or for local loopback stuff
So - 2^(32-32) - 2 = 0 - 2 = -2 is theoretical, but you’re not meant to assign multiple devices to /32. It’s for single-IP logic only.
📊 Why is IP address 32-bit?
IPV4 = 32 bits total = 4 bytes = 4 octets
Each IP address (like 192.168.1.1) is really:
1
11000000.10101000.00000001.00000001
Each octet = 8 bits → 8 × 4 = 32 bits total.
🔐 That gives us:
1
2^32 = 4,294,967,296 total possible IPv4 addresses
🗾 How to Interrogate Your Subnet with nmap?
You can use any IP in the subnet to nmap with.
Because nmap with /29 means:
“Scan all 8 IPs in the
192.168.66.64/29range, no matter where I start from.”
✅ The Real Magic
nmap interprets the CIDR mask, not just the starting IP.
So all of these are equivalent and will scan the exact same range:
1
2
3
4
5
nmap 192.168.66.64/29
nmap 192.168.66.65/29
nmap 192.168.66.66/29
nmap 192.168.66.67/29
nmap 192.168.66.70/29
All of them will scan:
1
2
3
4
5
6
7
8
192.168.66.64
192.168.66.65
192.168.66.66
192.168.66.67
192.168.66.68
192.168.66.69
192.168.66.70
192.168.66.71
🧠 Because /29 says:
Subnet mask =
255.255.255.248Meaning: 8 IPs, starting from the nearest multiple of 8 below or equal to your input IP
So even if you enter 192.168.66.69/29, it’ll still calculate:
1
Base: 192.168.66.64 → + 8 IPs
⚠️ But keep in mind
| IP | Role |
|---|---|
192.168.66.64 | Network address (unreachable) |
192.168.66.71 | Broadcast address (won’t reply to pings/ports) |
So realistically, only .65 to .70 might respond.
✅ Best Practice Scan:
1
nmap -sn 192.168.66.64/29
-sn→ “Ping scan” (don’t port scan, just host discovery)
Want to see open ports too?
1
nmap -p 22,80,443 192.168.66.64/29
💡 “Devices won’t always reply to ping if ICMP is disabled - try
-Pnif a host seems down but you suspect otherwise.”
🧝🏻 A Touch of Magic: Hosting with python3 -m http.server
1
python3 -m http.server --bind <your_ip> 8080
Which means:
“Run a simple HTTP server (a tiny website!) on port 8080 and bind it to this IP address only.”
Now, any device in the same subnet that can route to that IP:PORT combo can access your ENTIRE working directory in a browser.
💡 Let’s break it down:
| Thing | What it does |
|---|---|
python3 -m http.server | Starts a basic file server over HTTP |
--bind 192.168.X.X | Binds to a specific IP address |
8080 | TCP port number (browser will look here) |
Suppose your PC’s private ip is 192.168.1.73,
So when you visit:
1
http://192.168.1.73:8080/
your Phone is sending a GET request to:
- IP
192.168.1.73 - Port
8080 - Using protocol
HTTP
Then your PC replies with:
“Yo 👋 Here’s the entire folder contents of wherever I ran that command.”
🕸️ Tech Layers Behind the Magic:
When you accessed your Python HTTP server from your Phone, you activated four layers of the OSI model to make that one magical moment happen:
| OSI Layer | What was happening? |
|---|---|
| 🌐 L7 - Application (HTTP) | HTTP server runs in Python → serving files |
| L6 - Presentation | Browser formats your file list nicely (HTML rendering) |
| L5 - Session | TCP session established - a persistent, stateful connection |
| 🔢 L4 - Transport (TCP) | TCP handshake on port 8080 (SYN, SYN-ACK, ACK) |
| 🌍 L3 - Network (IP) | IP routing between your Phone & PC |
| L2 - Data Link | MAC address & ARP resolving |
| 🧭 L1 - Physical | Your Wi-Fi/Ethernet transmitting radio signals ⚡ |
So that moment? It wasn’t just “oh a browser opened a folder.”
It was your phone and PC cooperating across 5 network layers, dancing the protocol tango like pros. 👾
✨ This is classic Layer 7-3 cooperation. Your stack is alive and thriving.
🔓 Why this Feels Like a Magical Discovery
Because with this, you could:
- Ran a public-facing server
- Saw your own IP as a host
- Understood that any device on the same subnet can reach you via IP:PORT
- Realized you’re not just a client - you’re now a node. A server. A target. A controller.
💡 Any device with a known IP and open port becomes instantly reachable by any peer on its subnet.
🧠 Build Your Own Custom /29 Subnet and Link Up Your Phone, Laptop, and More
Check for Wi-Fi interface
Most desktop PCs (especially gaming/workstation towers) don’t come with a Wi-Fi card unless:
- You explicitly installed a PCIe Wi-Fi card
- Or you’re using a USB Wi-Fi dongle
Install the tool if you haven’t:
1
sudo apt install iw
So if you run:
1
iw list
…and it shows nothing or no AP mode?
Then yeah - you have no Wi-Fi interface at all or the one you have doesn’t support Access Point mode.
🧪 Double-check what interfaces you have
1
ip link
If you only see:
1
2
lo
enp3s0
(no wlan0, wlp*, or wlan1) then you 100% don’t have a Wi-Fi card plugged in.
So the question is whether to set up a Wi-Fi access point on your PC, or just build it using a laptop that already has Wi-Fi and can run things like hostapd, subnet empires, and more.
😾 Here I’ll go with laptop and iPhone.
🤨 Who Should Be the Router Now?
When you tether your laptop to an iPhone, you get dropped into a separate subnet (172.20.10.x) that’s NATed and isolated - perfect for sneaky or secure file transfers. That subnet isn’t visible to other machines on your corporate LAN.
It’s basically like your iPhone becomes the router, and your laptop is sitting quietly inside that subnet. Way safer when you’re at school, work, or anywhere you want some real privacy.
This is exactly what advanced security-minded folks do:
Use a tethered iPhone
Transfer tools/files to/from phone
Stay invisible to IT monitoring
But here’s the twist:
What we actually want is to build a custom subnet - something like 192.168.66.65/29.
The problem? You can’t easily reassign the iPhone’s hotspot IP range.
So yeah… we’ll need to mess with the laptop instead, aka let your laptop be the router.
🚥 Activate the Hotspot on Laptop
Before we go any further, to avoid IP conflicts, make sure you haven’t already assigned the IP we plan to give the laptop to any of your Ethernet interfaces.
If you have, clear it out with:
1
2
sudo ip addr flush dev eth0
sudo dhclient eth0
(Replace eth0 with your actual interface name.)
Then start the hotspot you’ve created it from the GUI
1
nmcli connection up <connection-name>
Hotspot Setup
| Setting | Status |
|---|---|
| Mode | Access Point |
| WPA2 password set | via Wi-Fi Security |
Edit the hotspot profile:
- IPv4 Method: Manual
Assign your laptop’s static IP, e.g.
Address Netmask Gateway 192.168.66.66255.255.255.248(leave blank)
Save the profile. If it complains like:
method 'manual' requires at least an address or a route
✅ Just make sure to fill all 3 fields with something like:
1
192.168.66.66 255.255.255.248 192.168.66.66
- ✅ Check “IPv4 is required for this connection”
run a real dnsmasq
✅ Step 1: Install dnsmasq
1
2
sudo apt update
sudo apt install dnsmasq
This will:
- Install
dnsmasq - Create
/etc/dnsmasq.d/directory - Register the
dnsmasq.servicewithsystemd
✅ Step 2: Enable & start it
After installing:
1
2
sudo systemctl enable dnsmasq
sudo systemctl start dnsmasq
If you already wrote your config like:
1
2
3
4
5
# /etc/dnsmasq.d/my-subnet.conf
interface=wlan0
dhcp-range=192.168.66.66,192.168.66.70,255.255.255.248,12h
dhcp-option=3,192.168.66.66 # Gateway
dhcp-option=6,8.8.8.8 # DNS
Then just:
1
sudo systemctl restart dnsmasq
NAT forwarding
Right now:
- You’ve got a working DHCP subnet (
192.168.66.64/29) - iPhone gets IP and connects fine
- But no internet access, because there’s no NAT (masquerading) from wlan0 → eth0
There it is - classic NAT forwarding problem.
🛠️ FIX: Enable NAT with iptables
1
2
3
sudo sysctl -w net.ipv4.ip_forward=1
sudo iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE
Explanation:
| Command | Purpose |
|---|---|
ip_forward=1 | Allows laptop to route packets between networks |
MASQUERADE | Translates packets from iPhone to look like they’re from laptop |
If it works and you want to make it permanent next boot:
Enable IPv4 forwarding:
1
sudo nano /etc/sysctl.conf
Uncomment or add:
1
net.ipv4.ip_forward=1
Save NAT rule permanently:
Install iptables-persistent:
1
2
sudo apt install iptables-persistent
sudo netfilter-persistent save
Now try to test if iPhone get the Internet. If something went wrong here, try restarting NetworkManager.
1
sudo systemctl restart NetworkManager
Wait a few seconds. Then retry:
1
nmcli connection up <connection-name>
If it doesn’t save the rule when reboot:
✅ 1. make ip forwarding permanent
Edit this file:
1
sudo nano /etc/sysctl.conf
Make sure you have:
1
net.ipv4.ip_forward=1
Then ALSO create a config in /etc/sysctl.d/99-hotspot.conf to override anything ignored:
1
echo "net.ipv4.ip_forward=1" | sudo tee /etc/sysctl.d/99-hotspot.conf
Apply instantly:
1
sudo sysctl --system
✅ Verify:
1
cat /proc/sys/net/ipv4/ip_forward
→ Should say 1
This double method ensures it’s applied at boot - even if NetworkManager or some weird systemd thing resets /proc.
✅ 2. ensure NAT rules load on boot
You’ve installed iptables-persistent - great!
Now run this to check your saved NAT rule:
1
sudo iptables -t nat -L POSTROUTING
You should see:
1
MASQUERADE all -- anywhere anywhere
If it’s there - now force reload on boot:
1
sudo systemctl enable netfilter-persistent
This ensures the NAT rule gets re-applied after all interfaces are up at boot time.
📱 Manually configure static IPs for other devices
Wanna customize your private IP?
On iPhone:
- IP:
192.168.66.67 - Mask:
255.255.255.248 - Gateway:
192.168.66.66 - DNS:
8.8.8.8(do not make it auto! must force a public resolver)
This(especially the DNS) tricks iOS into “trusting” the static connection.
Phew, so finally the whole thing would be like:
- Laptop:
192.168.66.66 - Phone:
192.168.66.67 - Tablet:
192.168.66.68 - Subnet mask:
255.255.255.248 - Gateway:
192.168.66.66(your host laptop)
🧠 What We Have Done in This Blog
We didn’t just talk theory - we built a functioning, custom subnet from scratch:
- 🛠️ Created a
/29subnet with tight IP allocation - 🔌 Configured manual IP addressing for fine-grain control
- 🧑🍳 Used
dnsmasqto cook up our own DHCP service - 🧱 Set up NAT and IP forwarding to let subnet clients access the Internet
- 🔍 Scanned & verified subnet activity with
nmap - 📡 Hosted a mini HTTP file server to test access
- 🧠 Understood the OSI stack magic happening underneath every request
You went from “what’s a subnet?” to “I built a subnet empire where I am the god of DHCP and gateway.”
💖 Support me with crypto or PayPal! 💘
💵 USDT (TRC20):
TJCANuMYSdgLKRKnpCtscXrS5NgDbBAvF9
🟠 Bitcoin (BTC):
bc1qrc9vhrrhnc9v9s9q9rjn24aj608j44p5hzsxft
Or support me on Ko-fi:
Any amount helps me continue creating content 💬💻
